S5239

DERA S5239 enterprise-class SATA SSD delivers outstanding performance, low latency and high reliability to optimize storage system while reducing TCO.

Functional Features
    • SATA 3 compliance

    • 112-layer 3D TLC NAND

    • 2.5-inch 7mm form factor

    • Up to 550/ 520MB/s sequential R/ W, Up to 95K/ 51K random R/ W IOPS

    • End-to-End data integrity protection

    • Power loss data protection

Product Features
Reduce Storage TCO
Outstanding Performance
Data Integrity Protection
DERA S5239 enterprise-class SATA SSD offers various capacities options, include 480GB to 3840GB in a standard 2.5-inch. The larger capacity drives require lower power consumption and cooling conditions than conventional HDD, advanced 112-layer 3D TLC NAND helps to reduce the storage total cost of ownership (TCO). DERA S5239 SATA SSD is ideal solution to upgrade your storage system.
Application and Load
  • Database

  • Virtualization

  • Streaming, CDN

  • Big Data Analytics

  • Software Defined Storage

Product Parameters
Product SeriesS5239
Capacity(TB)480GB,960GB,1920GB,3840GB
Form Factor2.5-inch 7mm
Host InterfaceSATA 6Gb/s
128KB Seq. R/ W [1]Up to 550/ 520 MB/s
4KB Rand. R/ W IOPS [2]Up to 95K/ 51K
ReliabilityUBER < 1 sector per 1017  bits read
Avg. R/ W Latency [3]122/ 24 µs
Power [4]Read/ Write2.6 W/ 3.4 W
Idle1.5 W
DWPD(5 years)1
Temperature0-70℃
Features

LDPC, End-to-End data protection, Power Loss protection


[1] 100%LBA, 128KB sequential R/ W, 32 queue depth with 1 worker.

[2] 100%LBA, 4KB random R/ W, 32 queue depth with 1 worker.

[3] 100%LBA, 4KB random R/ W, 1 queue depth with 1 worker.

[4] 100%LBA, Sequential R/ W power consumption is measured with 128KB, 32 queue depth and 1 worker. Random R/ W measured with 4KB, 32 queue depth and 1 worker.

*Performances measured using FIO in linux OS, result may differ according to testing platforms.1MB/s = 1,000,000 bytes/ second

Model List
Product SeriesPart NumberCapacityForm Factor
S5239DERAS32TGR0480WT480GB2.5" (7mm)
DERAS32TGR0960WT960GB2.5" (7mm)
DERAS32TGR01T9WT
1920GB2.5" (7mm)
DERAS32TGR03T8WT3840GB2.5" (7mm)
